Overhead Crane 5 Ton Capacity

Overhead Crane 5 Ton Capacity

Feature: Gantry Crane
Application: factory,workshop,outdoor
Warranty: 3 Year
Working Class: A3-A5
Power: 3P 220--440 V/50hz60HZ
Condition: New
Control method: Cabin Control/Wireless remote control
Place of Origin: Henan, China

Description

overhead crane 5 ton Description



A single-girder overhead crane is a type of bridge crane that consists of two or more overhead runways built into the building’s support structure, with the girder (the bridge) running between the runways for the width of the crane bay.

At each end of the girder are end trucks that move the girder and the hoist forward and backward along the length of the runways. The trolly and hoist most commonly run along the underside of the girder.

H786249fd5c71497d9f6b336958303f461

overhead crane 5 ton drawing





product-1-1

overhead crane 5 ton Details





333

overhead crane 5 ton Paramenters





Capacity (t) 3 5 10 16
Span (m) 12,16,20,24,30
Operational method Pendent Line With Press Button /Cabin/ Remote
Lifting Speed 8 ,8/0.8 8 ,8/0.8 8 ,8/0.8 8 ,8/0.8
travelling Speed 20 20 20 20
Electric hoist CD1/MD1 CD1/MD1 CD1/MD1 CD1/MD1
Lifting height(m) 6,9,12,18,24,30
Working duty A3, A4, A5,
Power supply 380V 60HZ 3phase AC (According to your demand )
overhead crane 5 ton features





✔ Crane traveling limit switch

✔ Weight overload protection device
✔ Lifting height limit device
✔ Voltage lower protection function
✔ Phase sequence protection function
✔ Emergency stop function
✔ Rain cover for outside hoist, driving units, electrical cubicle.
✔ Warning indicator: flashing lights and warning sound.
✔ Wireless infra-detector for anti-collusion

FAQ

Thanks for your time , In order to sending you right price , Please imform us your detailed needs for overhead crane .

1. crane rated load capacity ?

2.  the crane span ?

3. the crane lifting height ?

4. the working voltage ?

5. Do you need crane rail and cable  ?

6. other requirement ?
