Single Girder Small Light 3 Ton Gantry Crane
Feature: Gantry Crane
Application: factory,workshop,outdoor
Warranty: 3 Year
Working Class: A3-A5
Power: 3P 220--440 V/50hz60HZ
Condition: New
Control method: Cabin Control/Wireless remote control
Place of Origin: Henan, China
Description
3 ton gantry crane Description
Single girder gantry crane is a kind of track traveling midlight type crane, used together with CD, MD, HC model electrical
hoist,according to the shape, it also divided into MH type and MHLP type gantry crane. This product is a general-purpose using crane,which is mostly used for loading and unloading or grasping materials in open aerial and warehouses. The crane control mode have ground control and cabin control. The crane structural frame have truss type, box type, top box with truss leg type for choose.
3 ton gantry crane Drawing
3 ton gantry crane Details
Electric Single Girder overhead gantry crane parameter
PRODUCT SPECIFICATIONS
| Single Girder Gantry Crane Product Parameter | |
| Loading Capacity | 0.5~30t |
| Lifting Height | 3~30m or customized |
| Lifting speed | Single speed: 3~8 m/min or customized;Variable speed: 1/10 m/min |
| Span | 3~35m |
| Lifting mechanism | Wire rope hoist or electric chain hoist |
| Work duty | A3~A5 |
| Power supply | AC-3Phase-220//230380/400/415/440V-50/60Hz |
| Control method | Ground handle control(Push button),wireless remote control,cabinet control |
| Application area | Factory,workshop,warehouse,power station,logistic,etc. |
| Color | Customized |
| Working temperature | -20~40° |
| Protection class | IP54; IP55; IP65 |
Electric Traveling Single Girder Gantry Crane features
As safety is the most important concern for such big and heavy machines, all of our cranes are equipped with the following devices:
1. Crane traveling limit switch
2. Weight overload protection device
3. Lifting height limit device
4. Voltage lower protection function
5. Phase sequence protection function
6. Emergency stop function
7. Rain cover for outside hoist, driving units, electrical cubicle
Spare parts
Electric and other spare parts are packed by high quality plywood crate.
FAQ
Q 1: WHAT DO I NEED TO OFFER WHEN PURCHASING CRANES FROM YOU?
There are some necessary parameters about the cranes so you can tell us the lifting height,loading weight,span and other details you have. We can offer you a best solution.
Q 2:WHAT PAYMENT METHODS DO YOU HAVE?
You can choose the best way to pay and we have many kinds payment method ,such as westlink, paypal, L/C, T/T. Don't worry about this problem.
Q 3: WHAT AFTER-SALE SERVICE CAN YOU OFFER?
We are a professional machinery company so we will offer 24/7 service and whenever you have any doubts just contact us. We are happy to help you fix them.
Q 4: WHAT TRADE TERMS DO YOU USE?
We often use FOB price and we can change according to your requirements.
Q 5: HOW TO SHIP?
The most often shipment method is by sea,which is cheaper than by air. It depends on clients' decision. We will try our best to help you.
