Wall Travelling Jib Crane
Rated Lifting Moment: Customizable
Hoisting Mechanism: Wire rope/ chain rope electric hoist
Lifting Height: Customer's requirements
Control Method: Remote control
After Warranty Service: Video technical support
Color: Customized
Condition: New
Warranty: 5 Years
Place of Origin: Henan, China
Description
Wall travelling jib crane Description
The Wall travelling jib crane do not take any floor space and do not need special foundations. The cantilever is fixed on the wall or concrete post, and the rotation can be customized. The jib cranes are widely used in workshop, storage and ports, etc.
Wall travelling jib crane is a cost effective crane which travels along the rail mounted on the wall or other supported structure on elevated orbit of a multilayer assembly shop, making the full advantages of the working space. Wall travelling jib crane can provide long lateral movement of materials and at the same time can lift the objects in the vertical direction by the lifting equipment. The lifting capacity of wall travelling jib crane is 0.5 to 10 tons and working class is A3
Wall travelling jib crane parameter
| Model | LZ-125 | LZ-250 | LZ-500 | LZ-1000 | LZ-2000 | LZ-3000 | |
| Rated Capacity(KG) | 125 | 250 | 500 | 1000 | 2000 | 3000 | |
| Max.working radius R2(m) | L=200mm | ||||||
| Lifting speed(m/min) | 8/2 | 4/1,10/2.5 | 5/1.25,10/2.5 | 5/1.25,8/2 | 4/1 | 4 | |
| Horizontal running speed(m/min) | 7,14,28 | ||||||
| Elective power | 380-440V,3-PHASE,50/60Hz | ||||||
| Electric motor | Rotating motor(kw) | 0.37 | 0.37 | 0.37 0.55 | 0.37 0.55 | 0.55 0.75 1.1 | 0.55 0.75 1.1 |
Wall travelling jib crane drawing
Wall travelling jib crane features
1.Wall travelling jib crane offers long lateral transporting of materials without taking up floor space or interfering performance of large overhead cranes.
2.Wall travelling jib cranes can be lined up to handle materials in work stations and the length of crane runways is without limitation.
3.The most-effective material handling equipment for handling smaller lifts.
4.Handle or remote control operation on ground is provided which is easy, accurate, quick and efficient.
5.Customized material handling solution is available which can fully meet your requirements and application conditions.
6.Double block button is installed and the protection class is up to IP5.
7.The services life of wall travelling jib crane can high up to 500 thousand times.
