25 Ton Double Girder Hanger Overhead Crane

Product Name: 25 ton double girder hanger overhead crane
Feature: overhead Crane
Max. Lifting Height: 13m
Span: 18-35m
Duty class: A6-A8
Industrial Voltage: According to your request
Place of Origin: Henan, China
Warranty: 5 Years
Condition: New

Send Inquiry

Description

Products Description

Overhead cranes are large industrial cranes that are typically suspended from the ceiling or overhead structure of a building. They are used to lift and move heavy loads horizontally within a specific area. Overhead cranes typically consist of a bridge, end trucks, hoist, and trolley.

double girder overhead crane1

Products Drawing

Products parameter

Capacity	t	5	10	16	20
Span	m	10.5-31.5	10.5-31.5	10.5-31.5	10.5-31.5
Lifting Height	m	6-18	6-18	6-18	6-18
Lifting Speed	m/min	39.2	39.3	41.8	45.7
Trolley Speed	m/min	44.6	45.9	43.2	43.2
Crane Speed	m/min	93.6	112.5	98	87.3
Work Duty		A5-A6	A5-A6	A5-A6	A5-A6
Track Type		P43 or QU70	P43 or QU70	QU70 or 90*90	QU70 or 90*90

Products features

Sure! Here are some common features and components of overhead cranes:

1. Bridge: The bridge is the traveling part of the crane that moves horizontally along the runway rails. It is typically supported by end trucks or wheels. 2. End trucks: End trucks are attached to the bridge and hold the wheels that allow the crane to move along the runway rails. They can be motorized or manual depending on the crane design.

3. Hoist: The hoist is the component that is used for lifting and lowering the load. It typically consists of a motorized drum or chain that winds and unwinds to raise or lower the load. The hoist can have multiple lifting speeds and capacities depending on the specific requirements.

double-girder-overhead-traveling-crane
