Construction Project Beam Launcher Crane

Rated Loading Capacity: 50t-200t

Max. Lifting Height: 32m

Span:30m

Send Inquiry

Description

construction project beam launcher crane

Basic description of construction project beam launcher crane

_r4_c1_

Launcher girder crane is used for erecting concrete box girders for high speed (250km, 350km) passenger railway lines. This machine is suitable for equal span girders or different span girders which can be 20m, 24m and 32m, 50m. The rear part has two supports.

1. The bridge girder erection machine consists of main girder, crane, front legs, rear legs, front leg cylinder, rear leg cylinder and the transverse connection of front, middle, rear legs. The control part is composed of hydraulic system and electric control system.

2. Application: This product can be used not only in plain construction, but also to meet the construction of mountain highway slope, small radius curved bridge, skew bridge and tunnel bridge requirements.

Schematic drawing of construction project beam launcher crane Bridge launching girder 180T beam launcher machine for erecting concrete girders

Main technical parameter

Span	50m			40m		30m
Type	QJ200/50	QJ180/50	QJ160/50	QJ140/40	QJ120/40	QJ100/30	QJ80/30
Rated capacity	200t	180t	160t	140t	120t	100t	60t
Bridge span	30-50m			20-40m		20-30m
Max. slope	Longitudinal slope <5% cross slope <5%
Lifting speed	0.41m/min	0.45m/min	0.5m/min	0.56m/min	0.65m/min	0.75m/min	0.9m/min
Trolley longitudinal speed	3m/min
Trolley cross speed	3m/min
Crane slide longitudinal speed	3m/min
Crane side cross travel speed	3m/min
Adaptive inclined bridge angle	0~45°
Adaptive curved bridge radius	400m			300m		200m

Main features of construction project beam launcher crane

1. good stability, high effi ciency, safety and reliability; 2. Low deflection and high stiffness; 3. V ariable span convenient adjustm en t and convenient operati on; 4. Unique pin connection, firm and reliable, easy to install;

5. A-type fracture surface, continuous girder with low center of gravity, convenient and reliable;

6. The machine can accomplish the build of girders with carrying and erection at the same time.

Safety devices of construction project beam launcher crane

1. Overload protection: If the material is over the capacity, the crane will give a sharp warning for protection itself. 2. Emergency brake: If the operation staff encounter some emergency situation, we could start the emergency brake system to protection the related treasure. 3. Control Method: Room control or remote control to avoid any injure to the operation staff 4. Main lifting motor: with thermal protection and currency protection.

Inquiry notice ! ! !

If you want to inquire about our launching girder gantry crane, please confirm with us the details as below. Then we will quote you a suitable price more quickly.

1. Lift capacity? 2. Span? 3. Lift height? 4. Power supply in your local? 5. Nearest port? 6. What kind of goods will this crane lift?

Detail Pictures

Truss type double girder concrete beam launcher crane for highway and rail way
