Electric Winch Harbor Freight

Electric Winch Harbor Freight

Warranty:3year
Place of Origin:Henan China
Control:Remote control Press button control
Working duty:A3~A5
Power supply:3 Phase 380V 50Hz
Painting color:According to your requirements

Description





Products Description



202102040943106450778

Top quality with competitive price

Widely used in factory, mining, shipyard or double beam cranes

Compact structure and reasonable design

Easy to install, operate and maintenance

Low noise and good working condition



comparison of product parameters
Basic Parameters Rated Load Average Speed of Rope Capacity of Rope Rope Diameter Electromtor Power Overall Dimension Total Weight
Model KN m/min m mm KN mm kg
JK0.5 5 22 190 7.7 3 620×701×417 200
JK1 10 22 100 9.3 4 620×701×417 300
JK1.6 16 24 150 12.5 5.5 945×996×570 500
JK2 20 24 150 13 7.5 945×996×570 550
JK3.2 32 25 290 15.5 15 1325×1335×840 1011
JK5 50 30 300 21.5 30 1900×1620×985 2050
JK8 80 25 160 26 45 1533×1985×1045 3000
JK10 100 30 300 30 55 2250×2500×1300 5100


Product Center



1

QPQ electric winch

Precautions when using QPQ and QPK winch hoists: 1. The wire rope on the drum of QPQ and QPK winch hoists should be arranged neatly. If it is found to be heavy or slanted, the machine should be stopped and rearranged. It is strictly forbidden to pull or step on the wire rope with hands or feet during rotation. The wire rope is not allowed to be completely released, and at least three turns should be retained. 2. The wire rope is not allowed to be knotted or twisted. If the wire is broken more than 10% within a pitch, it should be replaced.
2

Double lifting winch

A winch is a small and light lifting device that uses a drum to wind a wire rope or chain to lift or pull heavy objects. It is also called a winch. The winch can lift vertically, pull horizontally or tilt heavy objects. There are three types of winches: manual winches, electric winches and hydraulic winches. Electric winches are the main type. It can be used alone or as a component of machinery for lifting, road construction and mine hoisting. It is widely used because of its simple operation, large rope winding capacity and easy relocation. It is mainly used in construction.
3

QPK electric winch

Precautions when using QPQ and QPK winch hoists: 1. The wire ropes on the drum of QPQ and QPK winch hoists should be arranged neatly. If overlap or oblique winding is found, the machine should be stopped and rearranged. It is strictly forbidden to pull or step on the wire rope with hands or feet during rotation. The wire rope is not allowed to be completely released, and at least three turns should be retained. 2. The wire rope is not allowed to be knotted or twisted. If the wire is broken more than 10% within a pitch, it should be replaced.
4

Gate hoist winch

Precautions when using QPQ and QPK winch hoists: 1. The wire ropes on the drum of QPQ and QPK winch hoists should be arranged neatly. If overlap or oblique winding is found, the machine should be stopped and rearranged. It is strictly forbidden to pull or step on the wire rope with hands or feet during rotation. The wire rope is not allowed to be completely released, and at least three turns should be retained. 2. The wire rope is not allowed to be knotted or twisted. If the wire is broken more than 10% within a pitch, it should be replaced.







5

Curved door winch


6

Double gate hoist


7

Steel gate winch


8

Double lifting gate hoist







FAQ

  • Can i have a price?

  • After getting your parameters,we will offer you a accurate price.

  • Can I customize products?

  • Yes,we can provide customization service.

  • What's your delivery period?

  • Within 40 days after your prepayment received; exact period should be based on detailed requirements and actual period;

  • .Do you have engineer oversea installation service?

  • Yes; We have;

  • If we need urgently, can you delivery soon?

  • After we confirming the parameters and sign the order, we will give priority to the emergency order to meet your needs;

  • Do you offer after-sales service?

  • We have after-sales team to support you.

  • How long will it take to ship to my country?

  • For international shipping, it depends on the product quantity and delivery address. For a specific estimate, please provide these details so that I can quote the most cost-effective option
