small mobile gantry crane

small mobile gantry crane

Lifting capacity is from 2~ 16ton,

span from 5~ 35m

temperature -20°C ~ +40°C.

Wire rope: 6*37+1

Mechnism: lifting and traveling

single girder workshop gantry crane price is a track travelling small and medium-sized crane. It consists of the door frame (girder, leg and the lower beam, etc.), electric hoist, crane operation mechanism and electric control parts. The crane uses legs to support the bridge, and the electric hoist. The crane legs travel on fixed rails embedded in, or laid on top of the floor. If there are special requirements for weight lifting and other parameters, we can customize them according to the user's needs.

1.  It is used together with CD, MD and other models of electric hoist. The hoist runs on i-beam. Also can equipped with many lifting device for special work.

2. Working class is A3, there are two operating types , ground control and cabin control.

3. Power is supplied by cable or slide wire.

4. Application: widely used at open ground and warehouses to load, unload or grab materials. 5. Prohibition: lifting melt metal, flammable, explosive, corrosion, overloading, dust and other dangerous operations.




 Schematic drawing

Main features

1. Cut Down your cost in building of plant and workshop;

2.  Improve your production efficiency;

3. Be suitable for indoor warehouse and outdoor usage;

4. Reduce daily maintenance;

5. Safety with high performance.


Safety devices

1. Weight overload protection device.

2. Top quality long time bearing polyurethane materials buffer.

3. Crane  traveling  limit switch.

4. Voltage lower protection function.

5. Emergency stop system.

6. Current overload protection system and so on.


Our Service

1. We have a professional sales team,can privede u a quick and professional reply.

2. Exclusive engineer support at any time, so we can design within 24 hours.

3. 2 year warranty for whole machines, providing all parts free of charge.

4. Low charge for continue maintenance when warranty is expired.

5. can produce the largest tonnage crane,just give us your demand.

6. We can provide free training to end-users, don't worry about the installation.


Inquiry notice ! ! !

If you want to inquire about our gantry crane, please confirm with us the details as below. Then we will quote you a suitable price more quickly.

1. Lift capacity?

2. Span?

3. Lift height?

4. Power supply in your local?

5. Nearest port?

6. What kind of goods will this crane lift?
