Rail Mounted Overhead Gantry Crane
The crane is mainly composed of gantry metal structure, cart running mechanism, trolley, electrical equipment and so on. 1. Metal structure of door frame The door frame is composed of the main beam, supporting leg, upper beam, ground beam, balance trolley and other parts. The control room,...
Description
Products Description
Double Girder Gantry Crane Double Beam Gantry Crane Mainly made up of bridge, trolley, crane traveling mechanism
and electric system.
Applies to the open warehouse or rail along for general handling and lifting work. Can equipped with many lifting device for special work.
Normally, double girder gantry crane lifting capacity: 5 ton~200 ton
MG double girder gantry crane lifting equipment Lift capacity: 3-200 ton
Span: 5-35 m
Work duty: A5-A7
Application
Product Paramenters
Safety devices
1. Overload Limiter ; Limit Switch (Lifting and Traveling) ; Short-circuit protection.
2. Interlock protection device ; Under-voltage protection ; Buffer ; Zero protection.
3. Rail tongs, Anchor device and Motor overload protection.
4. Rail clear plate and e mergency stop system.
5. Protective cover and c urrent overload protection system.
6. Bus Bar prevent plate and s ecurity chain protection.
7. Anti-collision device and g round protection.
1. Overload Limiter ; Limit Switch (Lifting and Traveling) ; Short-circuit protection.
2. Interlock protection device ; Under-voltage protection ; Buffer ; Zero protection.
3. Rail tongs, Anchor device and Motor overload protection.
4. Rail clear plate and e mergency stop system.
5. Protective cover and c urrent overload protection system.
6. Bus Bar prevent plate and s ecurity chain protection.
7. Anti-collision device and g round protection.
Details Images
Our Advantages
Product packaging
Exhibition
After-sale Service
| I-MGH Gantry Crane | ||||||
| No. | Item | Specification | ||||
| 1 | Safe working Load | 40T | ||||
| 2 | Girder Type | Box | ||||
| 3 | Span (gauge) | 18M | ||||
| 4 | Spreader lifing direction | Same direction with train / vertical to main girder | ||||
| 5 | Valid lifting Height | 7.5M | ||||
| 6 | Working Class | ISO A4 / FEM 1Am | ||||
| 7 | Static Testing of Main Girder | 1.25 | ||||
| 8 | Dynamic Testing of Main Girder | 1.1 | ||||
| II-Hoisting Trolley Assembly | ||||||
| 9 | Capacity | 40T | ||||
| 10 | Working System | ISO M4 / FEM 1Am | ||||
| 11 | Main Lifting | Motor Model | ZD152-4(ZDS1)18.5Kw | |||
| Speed | 2.3m/min | |||||
| 12 | Trolley Traveling | Speed | 10m/min | |||
| Motor Model | YDE100L1-4/2.2Kw | |||||
| III-Crane Traveling Mechanism | ||||||
| 13 | Span | 18M | ||||
| 14 | Working System | ISO M5/ FEM 2Am | ||||
| 15 | Lengthways Travel Speed | 26m/min | ||||
| 16 | Motor Model | YZR160M1-6 | ||||
| 17 | Motor power | 6.3Kw*2 | ||||
| IV-Other Description | ||||||
| 18 | Power Supply | 380V/50HZ/3P | ||||
| 19 | Power Supply Model | Cable reel | ||||
| 20 | Operation Type | Wireless remote | ||||
| 21 | Max wheel pressure | 248Kn | ||||
| 22 | Insulation Grade | F | ||||
| 23 | Working Temperature | 0~ 50℃ | ||||
| 24 | Colour | According to customers' demands | ||||
