3ton 5ton Column Cantilever Crane

3ton 5ton column cantilever crane Introduction

The working strength of cantilever crane is light. The crane is composed of a vertical column, a rotary arm driving device and an electric hoist. The lower end of the vertical column is fixed on the concrete foundation through a foot bolt, and the cantilever is driven by a cycloid pinwheel decelerating device. The electric hoist runs in a straight line from left to right on the cantilever I-beam and lifts heavy objects. The crane boom is hollow steel structure, light weight, large span, large lifting weight, economic and durable. The built-in walking mechanism adopts special engineering plastic wheel with rolling bearings, which has small friction force and light walking speed, and small structure size, which is especially conducive to improving the trip of the hook.

3ton 5ton column cantilever crane Parameters

3ton 5ton column cantilever crane Drawings

Production features

1) Light weight;

2) Arm length (maximum large working diameter 10m); 3) Large lifting capacity (lifting tonnage: 0.125t-0.5t); 4)Accurate positioning and flexible operation 5) Simple installation and simple maintenance;6) It can shorten the handling time and increase the work efficiency

Package and Delivery

Electric parts are packed by high-quality plywood crate, to reduce distortion in conveying.

Main beams, end beams, and trolly/winch are packed by plastic woven cloth. It can reduce abrasion during transportation.

If the size is suitable for container ship, usually by container.

Big size, usually by bulk ship or by container after truncation.

Transport ways are based on reducing costs & keep safety.

FAQ

Looking forward to receive your enquiry with the below details information:

1. Lifting capacity(t)

   2. Lifting height(m)

   3. Span(m)

   4. Power source: v/ hz/ phase

   5 Materials to be lifted

   6. Crane working time per day(h)

   7. Crane working environment

   8. Other special requirements
