Underslung Bridge Crane
Product model:LX
Lifting capacity: 1-25t
Span length: 7.5-31.5m
Lifting height: 6-30m
Lifting speed: 0.3-8m/min
Hoist travelling speed: 20m/min
Crane travelling speed: 20m/min
Working class: A3,A4
Description
Underslung Bridge Crane Description
Underslung Bridge Crane is suitable for places where the height from the track surface of the factory and warehouse buildings to the lower chord of the roof truss does not exceed 500 mm.
The lifting mechanism of this type overhead crane is CD/MD electric hoist to load and unload with flexible structure and safely traveling.
Control methods:
LX type Suspension single girder electric overhead mobile crane is generally used in warehouse with low headroom,So ,cabin control is not suitable for this type crane. Pendant line button control and wireless remote control are main control ways.
Underslung Bridge Crane Safety Devices
■ Overload limit switch
■ Electrical protection device
■ Emergency stop system
■ Low voltage protection function
■ Current overload protection system
■ Lifting height limiter
Underslung Bridge Crane Design Drawing
Underslung Bridge Crane Parameters
| Technical Parameters | |||
| Crane Traveling Mechanism | Working speed(m/min) | 20, 30 | |
| speed ratio | 58.78/39.38/26.36 | ||
| motor | type | ZDY 12-4 | |
| power(kw) | 2x0.4, 0.8x2 | ||
| rotational speed(n/min) | 1380 | ||
| Lifting Mechanism & electric mechanism | Hoist Type | CD, MD | |
| lifting speed(m/min) | 8(8/0.8);7(7/0.7) | ||
| lifting height(m) | 6, 9, 12, 18 | ||
| traveling speed(m/min) | 20,30 | ||
| motor | cone squirre cage model | ||
| lifting capacity(t) | 0.5~10 | ||
| Working Class | A3~A5 | ||
| Span | 3~16m | ||
| Power Supply | 380V 50Hz three-phase | ||
| Wheel diameter | Ø130 | ||
| Width of trail | 120a~163c | ||
Underslung Bridge Crane Main Parts
Certifications
Packing and Delivery
■ 100% QC inspection before shipment;
■ All frangible accessories will be protected by plastic papers and then packaged in wooden box;
■ Delivery time: strictly performer based on contract;
After-sales Warranty
■ 24 months warranty from the date of B/L
■ One year quick-wear parts for free
■ Professional technicians provide installation, commissioning services.
■ Technical advisory for any time.
