Eot Overhead Crane
QD type electric double girder bridge crane adopts series of products manufactured by international advanced standards. The whole machine has novel structure, beautiful appearance, good craftsmanship, flexible and stable operation, safe and reliable. main feature: (1) The bridge frame adopts...
Description
Main Features
1) Capacity :customized according to clients needs
2) Span: customized according to clients needs
3) Working Grade:A5~A8
4) High load handling capacity
5) High working efficiency
6) Easy for maintenance and fix
7) Wireless remot is available
8) Cabin room control as option.
LH model double girder overhead crane
It adopt A5 work duty group to handle medium heavy material lift work.
QD type double girder overhead crane
It suitable for most of heavy duty lift work who owns A5-A6 work duty group.
QE type double girder overhead crane
There are 2 independent trolleys traveling on main beam, the synchronous operation can be realized also. This crane is suitable for long material lifting such as: wood, paper tube, pipe and bar.
QZ type double girder overhead crane
Grab crane are widely used for steel factory to grab shredded scrap and port to grab sand and stone, or to grab gabage handling.
QC type double girder overhead crane
It equipped with electro magnet to handle material, ambient temperature or high temperature steel products material lifting.
QL type double girder overhead crane
It adopt the rotated lift beam with electro maget or rotated trolley to realize the material stockpiling.
YZ type double girder overhead crane
It mainly used at the place where th emolten metal lifted, it also have double beam option and four beam option accordingly.
QDY type double girder overhead crane
It mainly used at the place where th emolten metal lifted, thermal protective coating is added at the bottom of the main girder.
Main beam and end carriage
1. The bridge girder is designed to the current CMAA specifications and can be engineered to meet other local codes and regulations.
2. Dual motor bridge drives are standard, Other drive types are available upon request.
3. Bridge wheels are flanged with anti-friction bearings.
4. Rail sweeps and rubber bumpers are standard
Lift machenism
1. The hoisting machinery consists of a Kuangshan heavy duty industrial type standard wire rope unit mounted on a low headroom type trolley.
2. Motors are totally enclosed fan cooled, hoist duty with Class "F" insulation.
3. Gears are precision machined from alloy steel and induction hardened. All gearing is enclosed in a rugged steel housing and is oil splash lubricated.
4. Steel wire rope drums are precision machined.
Electrical control part
The electrical panel is suitable to operate over a wide range and features a modular design. The circuitry is fuseless with proper wiring in ducts and the terminals are kept non-screwed to allow easy installation and maintenance. Protection device exists in every drive group to prevent motor overload, which results in successful operation.
Cabin room
