Electric Powered Material Handling Transfer Cart
Condition: New
Warranty: 3 years
MOQ: 1 Set
Control Method: Remote Control
Power supply: Battery
Brand Name: Dowell Crane
Color: Customer Requirement
Place of Origin: Henan, China
Description
Electric Powered Material Handling Transfer Cart Introduction
Electric powered material handling transfer cart often called rail transfer carts, rail push carts or rail material carts, are ideal for manufacturing facilities and railway networks. Designed for low speed applications, Electric powered material handling transfer cart are not intended for use in high speed applications. These electric powered material handling transfer carts are used for moving large loads of equipment or specialized machinery on rail at slow speeds. Models are available for capacities up to 60 tons. All models are provided with a standard mechanical parking brake, sealed bearings, and heavy duty wheels and axles.
Electric Powered Material Handling Transfer Cart Parameters
| Model | KPX-2t | KPX-20t | KPX-50t | KPX-100t | KPX-150t | |
| Rated Load(t) | 2 | 20 | 50 | 100 | 150 | |
| TableSize(mm) | Length(L) | 2000 | 4000 | 5500 | 6500 | 10000 |
| Width(W) | 1500 | 2000 | 2500 | 2800 | 3000 | |
| Heigth(H) | 450 | 550 | 650 | 850 | 1200 | |
| Wheel Base(mm) | 1200 | 2800 | 4200 | 4900 | 7000 | |
| Rail Inner Gauge(mm) | 1200 | 1435 | 1435 | 2000 | 2000 | |
| Wheel Diameter(mm) | 270 | 350 | 500 | 600 | 600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance(mm) | 50 | 50 | 50 | 75 | 75 | |
| Running Speed(mm) | 25 | 20 | 20 | 20 | 18 | |
| Motor Power(kw) | 0.8 | 2.5 | 5.5 | 11 | 15 | |
| Max Wheel Load(KN) | 14.4 | 77.7 | 174 | 343.8 | 265.2 | |
| Reference Weight(t) | 2.3 | 5.5 | 7.6 | 13.9 | 26 | |
| Recommended Rail Model | P15 | P24 | P43 | QU100 | QU100 | |
Production Drawing
Electric Powered Material Handling Transfer Cart features
1. 1-ton to over 300 tons load capacity
2. Controlled direction of motion or steering ability
3. Lifting fixtures are available for simple transportation.
4. Remote control or fixed pendant
5. Increased maneuverability
6. Safety equipment options: warning horns, safety beacons, rail sweeps, anti-collisions detection devices, etc.
7. Two carts can be connected together for higher efficiency or longer goods.
8. Custom design to suit your cart requirements and its application
Certifications
Electric Powered Material Handling Transfer Cart applications
It is applied for transporting diesel engine, wind turbine, whole set electrical facility, industry boiler etc heavy industry.Load capacity, table size, speed can be chosen. Painting color and safety device can be customized as per customer need.
Hot Tags: electric powered material handling transfer cart China, manufacturers, suppliers, customized, quotation, offer, price
