4 Ton Electric Wire Rope Winch Supplier
Warranty:3 year
Place of Origin:Henan China
Control:Remote control Press button control
Working duty:A3~A5
Power supply:3 Phase 380V 50Hz
Painting color:According to your requirements
Description
4 ton electric wire rope winch supplier Description
The winch is a kind of lifting equipment that uses a winding drum to wrap a wire rope to lift or pull heavy objects. It is a powerful lifting and pulling tool used in various industries, such as construction, mining, shipyards, port, oil, terminal and other industrial applications. It can lift and pull heavy loads vertically, horizontally or on slopes. And we will follow our consistent commitment to quality, performance, and service of a commitment to customer satisfaction as our highest pursuit.
4 ton electric wire rope winch supplier Drawing
4 ton electric wire rope winch supplier parameters
| Model | Rated load | Rated speed | Rope capacity | Rope diameter | Motor power | Total Weight |
| KN | m/min | m | mm | KW | KG | |
| JK0.5 | 5 | 22 | 190 | 7.7 | 3 | 200 |
| JK1 | 10 | 22 | 100 | 9.3 | 4 | 300 |
| JK1.6 | 16 | 24 | 150 | 12.5 | 5.5 | 500 |
| JK2 | 20 | 24 | 150 | 13 | 7.5 | 550 |
| JK3.2 | 32 | 25 | 290 | 15.5 | 15 | 1200 |
| JK5 | 50 | 30 | 200 | 21.5 | 30 | 2310 |
| JK8 | 80 | 25 | 250 | 26 | 45 | 3000 |
| JK10 | 100 | 30 | 300 | 30 | 55 | 5100 |
4 ton electric wire rope winch supplier Applications
Winch machine for construction is often used to lift or pull heavy objects in various engineering projects on land and along the coast. There are two types of construction winches according to their functions:
Wire rope lifting winch that is used to lift materials vertically;
Wire rope pulling winch that is for horizontally pulling goods and materials.
Winch marine is mainly used on ships, docks or shores for anchoring, mooring and towing, as well as lifting and hauling heavy objects on board. According to the purpose, marine winches are divided into:
Wire rope anchor winch that is commonly found on the deck of the boat for anchoring purposes;
Mooring winch that is installed on the boat or on the shore to berth a ship or to support and position during loading and unloading;
Towing winch that is widely used on tugboats to tow other large vessels;
Slipway winch that is used to move various vessels to and from the water by the slipway.
